2007 Kitamura MyCenter HX630i Horizontal Machining Center in Toronto, Canada

Description

Kitamura MyCenter HX630i Horizontal Machining Center

Control: Fanuc Series 16i-MB

Run TIme: 9,467H 51M

Table Work Area - 630 MM X 630MM

Table Indexing - 4th axis 0.001

Max Work Size 1000 mm X 1100 mm

Table Load Capacity 1200KG

Travel

X Axis 1000mm

Y Axis 800mm

Z Axis 820mm

Distance From Table Center To Spindle Nose - 130 - 850mm

Distance From Table Surface To Spindle Center - 50 - 850mm

Spindle Taper NST No 50

Spindle Speed 35 - 1200 Min

Rapid Feed ( X Axis) Auto 50,000 mm/min

Rapid Feed ( Y Axis ) Auto 50,000 mm/min

Rapid Feed ( Z Axis ) Auto 50,000 mm/min

Cutting Feed 50,000 mm/min

Tool Storage Capacity 50 Tools

Tool Selection Method Random, Tool, Identified At Magazine

Spindle Motor

(30 min. Ratio ) Ac 26 Kw

Continuous Operation AC 22KW

ATC Motor AC 1500 W

Coolant Motor AC 730 ( 50HZ) 1210 (60Hz) W

Lubrication Pump Motor AC 20 W

Hydraulic Motor AC 2.2 Kw

Machine Weight With NC (45,540lbs)

Max Speed of spindle 12000 Min

Max diameter of tools 125 mm

Max weight of tools 20 kg

Power supply

AC 200/220V

3 Phase

50/60 Hz

5 KVA
